Embroidery Wilcom Es 2006 Keyboard Shortcuts key

Embroidery Wilcom Es 2006 Keyboard Shortcuts key


  1. start new design----------------------------:-Ctrl+N
  2. open design---------------------------------:-Ctrl+O or Alt+F+O
  3. close design---------------------------------:-Alt+F+C
  4. save design----------------------------------:-Ctrl+S or Alt+f+S
  5. save as---------------------------------------:-Alt+f+A
  6. print design---------------------------------:-Ctrl+P or Alt+f+p
  7. record to clipart----------------------------:-Ctrl+E
  8. show/hide Point & Stitch toolbar--------:-Ctrl+I
  9. show/hide Grid-----------------------------:-Shift+G
  10. show/hide Rulers and Guides------------:-Shift+G
  11. show/hide Overview window-------------:-Shift+V
  12. show/hide Color-Object List--------------:-Shift+L
  13. show Stitch List-----------------------------:-Shift+J
  14. open Lettering dialog----------------------:-A
  15. open digitizing tablet setup---------------:-Shift+D
  16. measure distance on-screen---------------:-M
  17. undo command------------------------------:-Ctrl+Z
  18. redo command-------------------------------:-Ctrl+Y
  19. cancel command-----------------------------:-Esc
  20. open online help-----------------------------:-F1
  21. exit application--------------------------------------------------:-Alt+F4
  22. finish digitizing object (keep last stitch)--------------------:-enter
  23. finish digitizing object (omit last stitch)--------------------:-spacebar
  24. finish digitizing Complex Fill/Fusion Fill boundary-----:-enter
  25. delete last input point-----------------------------------------:-bksp
  26. apply Satin stitch----------------------------------------------:-Shift+I
  27. apply Tatami stitch--------------------------------------------:-Shift+M
  28. apply Run stitch------------------------------------------------:-Shift+N
  29. switch between fill and run stitch----------------------------:-spacebar
  30. switch between fill and manual stitch------------------------:-enter
  31. switch between continuous and normal Input--------------:-Shift+A
  32. toggle Auto Underlay on/off----------------------------------:-U
  33. activate Auto Trace--------------------------------------------:-Ctrl+M
  34. activate Branching-----------------------------------------------:-I
  35. make Complex Shape vector object---------------------------:-Shift+H
  36. select all objects---------------------------------------------------:-Ctrl+A
  37. deselect all objects-----------------------------------------------:-Esc or X
  38. activate Select Object tool---------------------------------------:-O
  39. deactivate Select Object tool------------------------------------:-Esc
  40. select object at current needle position------------------------:-Shift+O
  41. select multiple objects-------------------------------------------:-Ctrl+Mouse Left Click
  42. select range of objects-------------------------------------------:-Shift+Mouse Left Click
  43. select next object-------------------------------------------------:- Tab Key
  44. select previous object--------------------------------------------:-Shift+Tab
  45. select object beneath---------------------------------------------:-Left Click double
  46. add next object to selection--------------------------------------:-Ctrl+Tab
  47. add previous object to selection---------------------------------:-Ctrl+Shift+Tab
  48. activate Polygon Select tool-------------------------------------:-Ctrl+L
  49. toggle Selects On/Off---------------------------------------------:-Q
  50. group selected objects--------------------------------------------:-Ctrl+G
  51. ungroup selected objects-----------------------------------------:-Ctrl+U
  52. lock selected object-----------------------------------------------:-K
  53. unlock all locked objects-----------------------------------------:-Shift+k
  54. toggle TrueView on/off-------------------------------------------:-T
  55. show/hide stitches--------------------------------------------------:-S
  56. show/hide outlines-------------------------------------------------:-L
  57. show/hide needle points-------------------------------------------:- . (period)
  58. show/hide connectors----------------------------------------------:-Shift+C
  59. show/hide function symbols--------------------------------------:-Shift+F
  60. show whole design-------------------------------------------------:-Esc
  61. fit design to window-----------------------------------------------:-F2
  62. hide others----------------------------------------------------------:-Shift+S
  63. show/hide image---------------------------------------------------:-D
  64. zoom in 2X---------------------------------------------------------:-Z
  65. zoom out 2X-------------------------------------------------------:-Shift+Z
  66. zoom to 1:1 scale (100%)----------------------------------------:-1
  67. specify zoom factor-----------------------------------------------:-F
  68. zoom box-----------------------------------------------------------:-B
  69. zoom box in Overview window--------------------------------:-Shift+B
  70. activate panning----------------------------------------------------:-P
  71. deactivate Auto Scroll---------------------------------------------:-Shift (Hold Down)
  72. center current stitch in design window--------------------------:-C
  73. return to previous view--------------------------------------------:-V
  74. redraw screen--------------------------------------------------------:-R
  75. activate Slow Redraw----------------------------------------------:-*Shift+R
  76. to start of design----------------------------------------------------:-Home
  77. to end of design-----------------------------------------------------:-End
  78. to next color---------------------------------------------------------:-Page Down
  79. to previous color----------------------------------------------------:-Page Up
  80. to next segment------------------------------------------------------:-Ctrl+Right Site
  81. to previous segment-------------------------------------------------:-Ctrl+Left Site
  82. to next object---------------------------------------------------------:-Ctrl+T
  83. to previous object---------------------------------------------------:-Shift+T
  84. 100 stitches forward------------------------------------------------:-+
  85. 100 stitches backward-----------------------------------------------:- (-)
  86. 10 stitches forward--------------------------------------------------:-Down key
  87. 10 stitches backward------------------------------------------------:-Up key
  88. 1 stitch forward-------------------------------------------------------:-Right Site key
  89. 1 stitch backward----------------------------------------------------:-Left Site key
  90. select/deselect stitches----------------------------------------------:-*Tab
  91. cut object-------------------------------------------------------------:-Ctrl+X
  92. copy object-----------------------------------------------------------:-Ctrl+C
  93. paste object-----------------------------------------------------------:-Ctrl+V
  94. duplicate object------------------------------------------------------:-Ctrl+D
  95. delete selected objects or last object------------------------------:-Delete
  96. activate Reshape Object tool--------------------------------------:-H
  97. activate Show Stitch Angles tool---------------------------------:-Alt+A
  98. activate Show Reshape Nodes tool-------------------------------:-Alt+N
  99. activate Stitch Angles too------------------------------------------:-Ctrl+H
  100. activate Stitch Edit tool---------------------------------------------:-E
  101. add stitch angles (Fusion Fill™)----------------------------------:-Ctrl+H
  102. check design integrity-----------------------------------------------:-1
